SKAN HOLZ Siena terrace roof
With the Siena terrace roof, you can create a protected, elegant and permanently usable outdoor space. The free-standing structure is ideal if mounting on the house wall is not possible or if you want to design your garden area flexibly. The result is a high-quality canopy that harmoniously combines functionality and a natural look.
- Free-standing terrace roof for maximum installation flexibility
- Solid design made of glued laminated timber (glulam spruce) for high stability and durability
- Choose from many differentsizes to suit your requirements
- Posts 12 x 12 cm including H-post anchors for setting in concrete in a foundation provided by the customer
- 16 mm polycarbonate multiwall sheets in clear version with UV-reflective layer
The structure made of solid glued laminated timber (glued laminated timber) made of Nordic spruce combines high load-bearing capacity with dimensionally stable, low-crack components. The factory colour treatment preserves the natural appearance of the wood and protects against UV and moisture damage.
Notes on surface treatment:
- The kit is pre-treated at the factory so that you can start assembly immediately after delivery.
- An enclosed repair quantity of glaze enables the professional post-treatment of drill holes and cuts.
- If you require additional finishing, we recommend light sanding and a coat of high-quality glaze after assembly.
The robust polycarbonate sheets ensure a pleasant and protected climate under the canopy. They are translucent, stable and have a UV-reflective coating. They are attached using high-quality aluminium profiles with EPDM lip seals, which ensures a reliable and durable design.
The H-anchors made of galvanised flat steel included in the scope of delivery enable secure anchoring in the point foundations to be constructed on site and make a decisive contribution to stability. This means that the terrace roof is ideally prepared for permanent outdoor use.
The Siena terrace roof is the perfect solution for anyone who values free-standing construction, solid wood quality and timeless design. It creates a sheltered area for relaxing hours outdoors and stylishly extends your living space to the outside.
Construction
The construction is made of glued laminate timber, consisting of several dried layers, attached to one another with finger-jointing. They are glued onto one another for weather-resistance. This results in a load-bearing beam which is more resistant to warping and less prone to fissures than naturally grown wood.
Colour treatment
The colour-treated components are coated with a layer of paint at the factory. The coating allows the natural wood grain to remain visible whilst ensuring a uniform surface finish. The components are coated on all sides twice at the factory, after which any excess material is brushed off.
Thanks to this factory pre-treatment, the components can be assembled immediately upon delivery. A primer coat prior to assembly is not required. Each kit also includes a quantity of wood stain or paint for touching up cut edges, screw holes or any damage caused during assembly. These areas should be treated in accordance with the installation instructions.
For a personalised finish, the visible wooden surfaces can be lightly sanded after assembly and treated with a suitable wood stain or paint. Components that have been colour-treated on all sides may show storage marks due to technical reasons.
Roof covering
The roof cladding consists of 16 mm thick polycarbonate multiwall sheets. The upper surface is coated with a UV-reflective layer. These are secured using aluminium profiles with EPDM lip seals.
Bracing
The building kit includes 60 cm-long H-post anchors of galvanized flat steel for embedding in concrete in the site-built deep foundation (for size and lay-out see assembly instructions). They firmly connect the posts to the subsurface to ensure high stability.
- Solid structure of glued laminate (BSH spruce)
- Free-standing
- Roofing: Polycarbonate sheet in clear
- posts 12 x 12 cm
- Including H-post anchors
